4K
High Quality Image Sensor
AMC-G4034K
High Quality Image Sensor
AMC-G403 AMC-G403
Professional High Quality
AMC series USB3.0 PTZ camera is equipped with a professional high quality 8 million pixel CMOS image sensor and a high-performance low-power SoC professional chip platform to continuously and stably output 4K View.
UHD Lens
Ultra High-Definition Lens Gives You a Higher-Definition Vision
-
High Definition ImagesThe camera gives you clear vision of the scenarios at 4K resolution
8.46MP CMOS Image Sensor
Clearly Displaying Any Image DetailsUSB3.0 PTZ Camera adopts 1/2.8” inch 8.46MP CMOS image sensor with resolution up to 4KP30, clearly displaying any image details, outputting smooth video without delay.
-
3X Optical ZoomRich Details
3X Optical Zoom
Crystal Clear from Far or NearWith 3X optical zoom and 5X digital zoom to easily meet the requirements of close-up and panorama views in various meeting scenes.
-
Wide HFOV & High-Precision Rotating PTZMeet the Needs of Various in Different Scenarios
Ultra Wide Angle
High Precision, Smooth Rotation, Quiet PTZSuitable for most streaming scenes, wide viewing angle high quality lens with High precision PTZ to meet your streaming needs.
-
Preset AreaSmooth Switching
256 Presets
Easy for SwitchesClose-up or panorama views can be switched at any time to improve the efficiency of the meeting.
-
Remote ControlConvenient Operation
One-Button Setting
Convenient and EfficientWith 3X optical zoom and 5X digital zoom, and with the help of infrared remote control.
-
Ergonomic DesignHigh Value Product Performance
Simple Design
Small and LightAttracted by its looking, fell into its quality. A perfect choice for video conference.
-
InterfaceSupport LAN, USB3.0
Applications
Personal Office/Huddle Room/Small Room/Medium Room
- Technical Data
- AMC-G403
-
Camera
- Image Sensor
- 1/2.8” CMOS, 8.46MP
- Focal Lens
- f=3.3mm~9.7mm
- Iris
- F2~F3.7
- FOV Horizontal
- 81.4°~31.3°
- Zoom
- Optical: 3X, Digital: 5X
- Focus
- Auto, Manual, PTZ Trigger, One Push Trigger
- AGC
- Auto/Manual
- White Balance
- Auto/Manual/Auto tracking/One Push/Specified Color Temperature
- Exposure
- Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
- SN Ratio
- ≥50dB
- BLC
- Support
-
PTZ
- Pan
- -170° ~ +170°, 0.1° ~ 120°/s
- Tilt
- -30° ~ +90°, 0.1° ~ 90°/s
- Preset Number
- 256
- Image Filp
- Support
-
Interface
- Network
- 1×RJ-45:1×10M/100M； 4KP30/P25, 1080P60/P50/P30/P25, 720P60/P50/P30/P25； 1. Image Compression: H.264/H.265,2. Protocol:ONVIF/RTSP/RTMP/TCP/UDP/SRT/RTMPS/GB28181; 3. Audio Compression: AAC/G.711
- USB3.0
- 1. Support UVC1.1; 2. UVC Support:H.264/H.265/MJPEG, Video resolution: 4KP30/P25, 1080P30/P25, 720P30/P25; YUY2/NV12: Video resolution: 1080P30/P25, 720P30/P25; 3. UAC Audio Format PCM
- Audio Interface
- 1 × LINE IN, 3.5mm
-
General
- Power
- DC12V, <12W
- Operating Environment
- Temperature: 0°C ~ +40°C, Relative Humidity: 10%RH ~ 90%RH
- Storage Environment
- Temperature: -20°C ~ +60°C, Relative Humidity: 10%RH ~ 95%RH
- Dimensions(L×W×H)
- 176mm × 137mm × 171mm
- Weight
- ≤1.2kg
