4KP60

Intelligent Algorithm Keeps Track of Teachers

LTC6-G500

4KP60

Intelligent Algorithm Keeps Track of Teachers

LTC6-G500

UHD Lecturer Tracking Camera

LTC6 series camera fast autofocus lens combines with depth intelligence algorithm to achieve efficient positioning and tracking of teachers, and improve classroom efficiency.

UHD Lens
Ultra High-Definition Lens Gives You a Higher-Definition Vision
  • LTC6-G500

    Sensor Size

    Pixel

    Focal Length

    Iris

    HFOV

    Optical Zoom

High Definition Images
The camera gives you clear vision of the scenarios at 4K resolution

4KP60
UHD Pictures

It delivers super UHD video for your lecture recording application.

Interface
Support HDMI, LAN, USB, Support H.264, H.265


Extraordinary Intelligent Tracking
Face Detection & Lock Tracking Algorithm
Feature One
Feature Two
Feature Three

In the Crowd

Automatically Identify & Lock Lecturer and Keep Tracking

Watch Video

Strong Ability

Track Even if Lecturer Wears Mask.

Watch Video

Intelligent Adjustment

Auto Adjust Tilt Angle as per Lecturer's Height.

Watch Video
Anti Interference
Not Affected by Moving Objects or External Environment
Feature One
Feature Two
Feature Three

Tilt Motion

while Tracking


Keep Tracking if Lecturer Stand among the Students.
Watch Video

Track Lecturer Only

Not Track Other Moving Object


Watch Video

Track with Lights On /Off

Not Track Moving Objects on Projector.


Watch Video
Applications
Traditional Classroom/Ladder Classroom/Training Room/Multimedia Classroom


LTC6-G500
Technical Data
LTC6-G500
  • Camera
    Image Sensor
    1/2.8"CMOS, 8.46MP
    Focal Lens
    3.4mm~40.3mm
    Iris
    F1.8~F3.6
    FOV Horizontal
    81°~7.6°
    Zoom
    Optical: 12X, Digital: 12X
    Focus
    Auto, Manual
    White Balance
    Auto/Manual
    Exposure
    Auto/Manual
    SN Ratio
    ≥55dB
    DNR
    2D/3D
    BLC
    Support
  • PTZ
    Pan Angle
    -130° ~ +130°; 0.2° ~ 80°/s
    Tilt Angle
    -30° ~ +90°; 0.2° ~ 60°/s
    Image Flip
    Support
    Preset Number
    64
  • Interface
    HDMI
    1×HDMI 2.0;Support 4KP60/P50/P30/P25, 1080P60/P50/P30/P25, 1080I60/I50,720P60/P50
    Network
    RJ45 (10M/100M/1000M), POE(Optional);1.Support 4KP60/P50/P30/P25, 1080P30/P25, 720P30/P25, 360P30/P25;2.Image compression H.264/H.265
    USB
    1×USB2.0;1.Support UVC 1.1;2.Image compression H.264/MJPEG; support 4KP30/P25, 1080P30/P25,720P30/P25, 360P30/P25
    3G-SDI(Optional)
    1×3G-SDI; support 1080P60/P50/P30/P25, 1080I60/I50,720P60/P50
    HD-BaseT(Optional)
    1×HD- BaseT; support 4KP30/P25, 1080P60/P50/P30/P25, 1080I60/I50,720P60/P50
    Audio Input
    1×Line In, 3.5mm
    Control Interface
    1×RS-232 In, 1×RS-232 Out
    DIP Switch
    Rotating DIP switch to set video format
    Power
    DC12V
  • General
    Protocols
    VISCA
    Power Consumption
    <18W
    Operating Environment
    Temperature: 0°C ~ +40°C, Relative Humidity: 10%RH ~ 90 %RH
    Storage Environment
    Temperature: -20℃ ~ +60°C, Relative Humidity: 10%RH ~ 95 %RH
    Dimensions (L×W×H)
    245mm×145mm×165mm
    Weight
    1.8KG
