Compact Design

Support Multiple Baud Rates
and Control Protocols

CKB-02V2

Compact Design

Support Multiple Baud Rates
and Control Protocols

CKB-02V2

Powerful but Small

Four-Dimensional Joystick, Ergonomic Design;
Feel Comfortable and Support Two-Level Password Protection;
Support Multiple Baud Rates and Control Protocols;
It Can Control 256 Devices with Different Addresses.

4D Joystick
Comfortable to Handle

Easy Operation of Joystick
User-Friendly Design

Ergonomic Design and Excellent Finishing
High Brightness OLED Display.


Powerful but Small
Palm Size

Compact Design

Rich Functions, Small Size, Easy to Hold and Carry.

Support Batch Operation
Wide Applicability

Easy Operation & Encryption Protection

Camera Configuration has Batch Operation Function;
Support Multiple Baud Rates and Control Protocols;
Support Two-level Password Protection.

Can Realize Multi Device Control
Convenient and Efficient

With Batch Operation Function

It can control 256 devices with different addresses.


Applications
Conference/Education/Training/Event


CKB-02V2
Technical Data
CKB-02V2
  • Technlcal Data
    Control Interface
    RS-485,RS-232
    Protocol
    Pelco-D, Pelco-P, VISCA
    Baud Rate
    2400bps, 4800bps, 9600bps, 19200bps, 38400bps
    Address
    0~255
    Joystick
    4-axis
    Display
    OLED
    Power
    DC12V
    Power Consumption
    <2W
    Working Temperature
    0°C~+40°C
    Storage Temperature
    -20°C~+50°C
    Relative Humidity
    <90%(non-condensation)
    Dimensions (LxWxH)
    200mm×120mm×103mm
    Net Weight
    0.5KG
