1080P60

Simultaneously Outputs of
HD and SD Videos

HMC-NS3003N

1080P60

Simultaneously Outputs of
HD and SD Videos

HMC-NS3003N

NDI HD Camera

1/2.8" CMOS Image Sensor, Up to 2.14MP; 30X Optical Zoom, 12X Digital Zoom, Up to 63.7° FOV

HD Lens
High-Definition Lens Gives You a Higher-Definition Vision
  • HMC-NS3003N

    Sensor Size

    Pixel

    Focal Length

    Iris

    FOV

    Optical Zoom

High Definition Images
The camera gives you clear vision of the scenarios at 1080P resolution

1/2.8" CMOS
Up to 2.14MP

Simultaneously Outputs of HD and SD Videos.


Timely & Clear
Very Low-Latency Video Transport

Powerful Processor
Advanced Technology

You will never miss any wonderful moment.

NDI Camera
Support NDI

NDI®|HX Enhanced

NDI® technology makes video creation and sharing accessible, easy and fun for millions.


HEVC Video Compression Capabilities
HEVC, or H.265, Offers about Double the Data Compression Ratio at the Same.

Video Quality Level and Substantially

Improve coding efficiency, saving 50%-60% of your bandwidth or storage space, or dramatically increasing video quality at the same bit rate.

Applications
Academic Lectures/Live Broadcast of Events/Live Broadcast of Activities/Outdoor Activities

HMC -NS3003N
Technical Data
HMC -NS3003N
  • Camera
    Image Sensor
    1/2.8" CMOS, 2.14MP
    Focal Lens
    f=4.3mm~129.0mm
    Iris
    F1.6~F4.7
    FOV Horizontal
    63.7°~2.3°
    Zoom
    Optical: 30X, Digital: 12X
    Focus
    Auto, Manual, PTZ Trigger, One Push Trigger
    Shutter Speed
    1/1 ~ 1/10,000s
    AGC
    Auto/Manual
    White Balance
    Auto, Indoor, Outdoor, One Push, Manual, Auto Tracking, Sodium Lamp, Fluo Lamp
    Exposure
    Auto, Manual, Shutter Priority, Iris Priority, Bright Priority
    SN Ratio
    ≥50dB
    DNR
    2D/3D
    WDR
    Support
    BLC
    Support
  • PTZ
    Pan Angle
    -170° ~ +170°, -30° ~ +90°
    Pan Speed
    0.1° ~ 120°/S, 0.1° ~ 90°/S
    Preset Number
    256
    OSD
    Yes
    Image Flip
    Yes
  • SDI Output
    Video Format
    1080P60/59.94/50/30/29.97/25, 1080I60/59.94/50, 720P60/59.94/50
  • Network
    Resolution
    Max support 1080P60
    Image Compression
    H.265/H.264
    Audio Compression
    AAC
    Protocols
    ONVIF/ RTSP/ RTMP/ HTTP/ TCP/ UDP
    Dual Stream
    Support
  • Interface
    Video Output
    1×3G-SDI, 1×HDMI
    Audio
    1×Line In , 1×Line Out
    Network Interface
    RJ45 (10M/100M) interface, NDI, Optional POE (Power over Ethernet)
    Control Interface
    1×RS-232 In, 1×RS-232 Out, 1×RS-485
    IR Throughout Output
    1×Ir throughout output
  • General
    Protocols
    VISCA (support daisy chain) / PELCO-P / PELCO-D
    Address
    0~63
    Power
    DC12V
    Power Consumption
    <20W
    Operating Environment
    Temperature: 0°C ~ +40°C, Relative Humidity: 10%RH ~ 90 %RH
    Storage Environment
    Temperature: -20℃ ~ +60°C, Relative Humidity: 10%RH ~ 95 %RH
    Dimensions (L×W×H)
    220mm×202mm×162mm
    Weight
    1.7KG
